250ZJ(G)-I-A75 Slurry pump

Shijiazhuang Heavy Pump Company Limited 6

Summary Description

1)Capacity:300-1480m³/h
2)Head: 20.8-97.5 m
3)Flow parts materials: Cr26 alloy
4)Allowable mating Mac power: 560 kw

$10543.00

PRODUCT DETAILS

Product description



8.jpgThe ZJ ( G ) series slurry pumps , which are created by Shijiazhuang Impurity Pumps Co ., Ltd , is a new generation anti - wear , energy saving , slurry pump . The ZJ ( G ) series pumps used international advanced solid - liquid two - phase flow theory and were designed using the Minimum - Wear Principle . The flow parts of this pumps are suitable for the flow of state media for it ' s set shape , which reduces hydraulic loss of eddy and impact , both in pump and along the pipeline ; so reduced friction of flow parts , lower noise and vibration of the pump translates into improved hydraulic efficiency .
The ZJ ( G ) series pumps are cased in hard - alloy which is a high anti - wear and high anti - corrosive impact resistance material , which means the pump will have a longer service life . In addition , this series pumps used an automatic reduced pressure system to avoid liquid leakage .
The ZJ ( G ) series slurry pumps are widely used in mining , metallurgy , power , coal and building material sectors . The ZJ ( G ) series pumps are suitable for handling abrasive and corrosive solids - bearing slurry with maximum concentrations of wt .45%( ash ) and wt .60%( ore ).
We have all kinds of ZJ ( G ) series slurry pumps , all of which can be made of directly driven ( DC ), directly driven via hydraulic coupling ( HC ), belt driven , and they can be operated in tandem and parallel positions according to the requirements of the customer .


Details Images


 Work environment


Product Paramenters
Type Max Power(KW) Clear water Performance Pump Weinght(KG)
Capacity(m³/h) Head(M) Speed(rpm) Max.Eff(%) NPSH(m)
250ZJ(G)-I-A103 560 402-1573 29.7-110.5 400-730 74.5 2.8 5085
250ZJ(G)-I-A96 560 403-1466 25.4-93.7 400-730 77.8 3.5 5035
250ZJ(G)-I-A90
450 378-1374 22.3-82.4 400-730 73.8 3.4 4980
250ZJ(G)-I-A85
800 376-1504 30.1-128.7 490-980 76.5 3.5 4530
250ZJ(G)-I-A83
800 367-1469 28.7-122.7 490-980 75.5 3.5 4514
250ZJ(G)-I-A80
710 354-1416 26.7-114.0 490-980 73.5 3.4 4490
250ZJ(G)-I-A78
630 415-1796 21.1-102.5 490-980 71.5 3.2 4474
250ZJ(G)-I-A75
560 300-1480 20.8-97.5 490-980 77.5 3.0 3480
250ZJ(G)-I-A73
500 292-1441 19.7-92.4 490-980 76.5 3.0 3466
250ZJ(G)-I-A70
450 280-1381 18.1-84.9 490-980 74.5 42.9 3446
250ZJ(G)-I-A68
450 272-1342 17.1-80.1 490-980 73.5 2.7 3432
250ZJ(G)-I-A65
315 299-1249 15.4-71.0 490-980 76.9 3.0 3020
250ZJ(G)-I-A63
315 290-1211 14.4-66.7 490-980 75.9 3.0 3008
250ZJ(G)-I-A60
280 276-1153 13.1-60.5 490-980 73.9 2.8 2991
Working principle
Types of accessories




Company Profile




Shijiazhuang Heavy Pump Company Limited is changed by Hebei Xinda Slurry Company. We continue the fine tradition of producing slurry pumps-be famouse for its quality and service.
All products are mainly supplied to mining, metallurgy, public works, coal, petroleum, chemical, building material and other national economic deparments. The products are sold well all China and far to more than 40 countries in the world.

Heavy pump products in five series: Heavy pump products advantage:
1)Heavy horizontal slurry pump H series. 1)Anti-abraisive metal.
2)Heavy vertical slurry pump SP ( semi-submersible pump) 2)Module design which makes the spareparts can be changed freely.
3)Heavy dredge pump G series 3)Designed and built for long time with low maintenance.
4)Heavy gravel pump T series Heavy Pump Company to the Customers:
5)Heavy submersible pump 1)Quality first. We guranteed every spareparts of the pump must be inspected closedly and will have our inspectors names on it.
Heavy Slurry Pump Material: 2)Fast delivery at your requirement.
a)Impeller: high-chromium alloy or rubber.
b)Volute liner: high-chromium alloy.
c)Shaft: 45# steel.
d)Shaft sleeve: ductile casting.
e)Frame plate: casting.

f)Packing seal: Mechanical seal or Gland seal.

We can choose the pump material according to pump working condition.

Production workshop corner


Use of Site


Enterprise production certificate


Customer Visit Photos




Packaging Transport Photos


FAQ

Q: How can I make order online?
A: Send email or message(whatsApp/ wechat) us.you can ask any question ,after we confirm the detail, we can make order.
Q: Do you have MOQ limit?
A: The MOQ is 1 set.
Q: Which payments are acceptable?
A: T/T, L/C, Western Union, Paypal.
Q: Which shipping terms are available?
A: By sea, air, Express.
Q: How about the delivery time?
A: Delivery time is normally 3-7 working days after confirm the money. Depends on your quantity.
Q: What's your warranties?
A: 1 year after delivery.
Q: Can I buy parts separately?
A: Yes, all of the pump spare parts can buy separately.
